- General Information
- Manufacturer
- QNAP Systems
- Manufacturer Website Address
- http://www.qnap.com
- Brand Name
- QNAP
- Product Line
- NASbook
- Marketing Information
TBS-464 | Compact, portable, versatile: Quad-core 4-bay M.2 NVMe SSD NASbook
Built to fit in everywhere, the TBS-464 M.2 NVMe SSD NASbook is ideal for modern offices, workgroups, meetings and multimedia. Powered by an Intel Celeron N5105 quad-core processor (burst up to 2.9 GHz), the TBS-464 has two 2.5GbE ports and USB 3.2 Gen 1 ports for accelerating file transfer and versatile applications. The TBS-464 provides M.2 NVMe SSD slots and supports HybridMount for creating hybrid cloud storage environments, has up to two 4K HDMI 2.0 outputs, media transcoding capabilities, and includes the KoiMeeter app for enabling video conferencing and wireless presentations for small businesses and remote workers.
2.5GbE connectivity
Both 2.5GbE ports are backwards compatible with 1GbE/ 100MbE/ 10MbE speeds. Up to 5 Gbps transfer speeds can be achieved by using port trunking.
SSD cache acceleration
Use up to four M.2 PCIe NVMe SSDs (sold separately) for ultimate storage performance.
USB port
Two USB 3.2 Gen 1 ports for faster data transfer.
4K HDMI output
Up to two HDMI 2.0 ports support 4K @60Hz output. Real-time transcoding is also supported, and the built-in IR receiver can be used by the RM-IR004 remote control for a more convenient NAS experience.
Snapshot protection against Ransomware
Snapshots fully record the system status and data, allowing you to protect files and data from accidental deletion and malware attacks.
Cloud storage gateway
Supports HybridMount cloud storage gateways for low-latency access to cloud data.Two 2.5GbE Ports with USB 3.2 Gen1 Connectivity for Greater Performance
The TBS-464 is powered by an Intel Celeron N5105 quad-core processor with 8 GB DDR4 memory, and has two USB 3.2 Gen 1 ports for faster data transfer. With two 2.5GbE ports the TBS-464 provides exceptional file transfer performance, and with Port Trunking can achieve speeds of up to 5 Gbps. The integrated Intel® AES-NI encryption engine also helps protect confidential data without impacting system performance.
Build a High-Speed 2.5GbE Network Environment
QNAP offers comprehensive, budget-friendly storage and networking solutions that provide an array of connectivity possibilities. Easily and flexibly upgrade your workplace or home network now to handle bandwidth-hungry applications.
-
A fast 2.5GbE NAS
A QNAP NAS features one or more 2.5GbE ports, and Port Trunking allows you to combine multiple ports for greater bandwidth potential.
-
Upgrade computers and servers
Servers and desktops can install PCIe-based QNAP network cards that support 10G/5G/2.5G/1G/100M Multi-Gig.
-
- Product Type
- SAN/NAS Storage System
- Storage
- Number of Solid State Drive Supported
- 4
- Flash Memory Capacity
- 4 GB
- Processor & Chipset
- Processor Type
- Celeron
- Processor Model
- N5105
- Processor Core
- Quad-core (4 Core)
- Memory
- Standard Memory
- 8 GB
- Memory Technology
- DDR4 SDRAM
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- I/O Expansions
- Total Number of Expansion Slots
- 4
- Controllers
- Controller Type
- NVMe
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 5, 6, 10, JBOD
- Interfaces/Ports
- HDMI
- Yes
- Total Number of USB Ports
- 5
- Number of USB 2.0 Ports
- 3
- Number of USB 3.2 Gen 1 Ports
- 2
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- Software
- Operating System
- QTS 5.0.1
- Management & Protocols
- Protocols
- SFTP
- DHCP
- SSH
- IPSec
- FTPS
- AFP
- CIFS/SMB
- FTP
- SNMPv2
- IPv4
- WEBDAV
- Telnet
- SSL
- iSCSI
- TLS
- HTTP
- NFS
- TFTP
- FXP
- DDNS
- IPv6
- PPTP
- LDAP
- L2TP
- Power Description
- Maximum Power Supply Wattage
- 65 W
- Physical Characteristics
- Height
- 30 mm
- Width
- 230 mm
- Depth
- 165 mm
- Form Factor
- Portable
- Weight (Approximate)
- 800 g
