- General Information
- Manufacturer
- Lenovo Group Limited
- Manufacturer Website Address
- http://www.lenovo.com/uk/en/
- Brand Name
- Lenovo
- Product Line
- ThinkSystem
- Product Series
- SR250 V3
- Marketing Information
The Lenovo ThinkSystem SR250 V3 is a high-value single-socket 1U rack server for growing businesses that need optimized performance and flexibility for future growth, along with enterprise-class reliability, management, and security. The server supports the new Intel Xeon 6300 Series processors or Intel Xeon E-2400 Series processors.
This product guide provides essential presales information to understand the ThinkSystem SR250 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR250 V3 and consider its use in IT solutions.
- Product Type
- Server
- Processor
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Manufacturer
- Intel
- Processor Type
- Xeon
- Processor Model
- 6353P
- Processor Core
- Octa-core (8 Core)
- Processor Speed
- 2.70 GHz
- Cache
- 24 MB
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C266
- Memory
- Standard Memory
- 16 GB
- Maximum Memory Supported
- 128 GB
- Memory Technology
- TruDDR5
- Error Checking
- ECC
- Total Number of Memory Slots
- 4
- Number of Occupied Memory Slots
- 1
- Signal Processing
- Unregistered (Unbuffered)
- Controllers
- Controller Type
- Serial ATA
- I/O Expansions
- Number of Total Expansion Bays
- 3
- Number of 3.5" Bays
- 3
- Number of LFF Bays
- 3
- Total Number of Expansion Slots
- 3
- PCI Express Details
- x8 LP, x8 LP, x8 Int
- Riser Card
- slot1: PCIe Gen4 x8 in x8 (LP); slot2: PCIe Gen4 x8 in x16 slot (LP)
- Display & Graphics
- Graphics Controller Manufacturer
- Matrox
- Graphics Controller Model
- G200
- Graphics Memory Capacity
- 16 MB
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 1
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- VGA
- Yes
- Number of VGA Ports
- 1
- Remote Management
- Yes
- Remote Management Controller
- XClarity Controller (XCC2) Platinum
- Operating System
- Operating System Supported
- Windows Server 2022
- Windows Server 2025
- Red Hat Enterprise Linux 8.10
- Red Hat Enterprise Linux 9.4
- Red Hat Enterprise Linux 9.5
- Red Hat Enterprise Linux 9.6
- Red Hat Enterprise Linux 9.7
- Red Hat Enterprise Linux 10
- Red Hat Enterprise Linux 10.1
- SUSE Linux Enterprise Server 15 SP6
- SUSE Linux Enterprise Server 15 SP7
- SUSE Linux Enterprise Server 16
- Ubuntu 22.04 LTS x64
- Ubuntu 24.04 LTS x64
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Plug/Connector Type
- C13
- Maximum Power Supply Wattage
- 800 W
- Redundant Power Supply
- Yes
- Hot Swappable Power Supply
- Yes
- Power Source
- Power Supply
- Physical Characteristics
- Form Factor
- Rack
- Rack Height
- 1U
- Height
- 43 mm
- Width
- 434.4 mm
- Depth
- 561 mm
- Weight (Approximate)
- 12.30 kg
- Miscellaneous
- Package Contents
- ThinkSystem SR250 V3 7DCL100FEA Server
- Documentation flyer
- Toolless Friction Rail v2
- 2 x Power Cord
- Security Features
- Power-on password
- Administrator's Password
- Trusted Platform Module ,supporting TPM 2.0.
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Certification
- China Environmental Labeling Program (CELP)
- GREENGUARD
- Energy Efficiency Certification
- China Energy Conservation Program (CECP)
- ENERGY STAR 4.0
- Energy Efficiency Compliance
- Energy-related Products Directive Lot 9 (ErP Lot 9)
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
