- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC
- Product Line
- Smart-UPS
- Product Series
- RT
- Marketing Information
The APC Smart-UPS RT is an online UPS with a power rating of 20kVA and output power capacity of 16000 watts. It includes multiple output connections such as IEC 60230 C19 and IEC Jumpers. This model is includes a lead-acid battery and is rack-mountable. It features a double conversion online topology, sine wave waveform type, and built-in bypass.
- Packaged Quantity
- 1 Each
- Product Type
- Online UPS
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Plug/Connector Type
- Hard Wire 3-wire
- Hard Wire 5-wire
- Receptacle Type
- Hard Wire 3-wire
- Hard Wire 5-wire
- IEC 60320 C19
- IEC Jumper
- Receptacle Detail
- 1 x Hard Wire 3-wire
- 1 x Hard Wire 5-wire
- 8 x IEC 60320 C19
- 2 x IEC Jumper
- Overload Protection
- Yes
- Power Description
- Load Capacity (VA)
- 20 kVA
- Input Voltage
- 220 V AC
- Output Voltage
- 230 V AC
- Input Frequency
- 70 Hz
- Output Frequency
- 60 Hz
- Input Current
- 111 A
- Management
- Network Management
- SNMP Manageable
- Bypass Switch
- Automatic
- External (Optional)
- Internal
- Manual
- Static
- Emergency Power OFF
- Yes
- Interfaces/Ports
- Serial Port
- Yes
- Network (RJ-45)
- Yes
- Modular Slots
- SmartSlot
- Battery Information
- Battery Characteristics
- Maintenance-free/Sealed/Spill Proof
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 4.90 Minute
- Backup/Run Time (Half Load)
- 15.30 Minute
- Typical Battery Recharge Time
- 2.50 Hour
- Physical Characteristics
- Color Family
- Black
- Form Factor
- Rack/Tower
- Rack Height
- 12U
- Height
- 533 mm
- Width
- 432 mm
- Depth
- 773 mm
- Weight (Approximate)
- 247.73 kg
- Miscellaneous
- Package Contents
- Smart-UPS RT 20kVA Tower/Rack-mountable UPS
- CD with Software
- Rack Mounting Support Rails
- Smart UPS Signaling RS-232 Cable
- User Manual
- Web/SNMP Management Card
- 4 x Battery Modules
- REACH Declaration URL
- https://download.schneider-electric.com/files?p_Doc_Ref=SURT20KRMXLI_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
- EU RoHS Declaration URL
- https://download.schneider-electric.com/files?p_Doc_Ref=SURT20KRMXLI_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
- Environmental Profile Availability
- https://download.schneider-electric.com/files?p_Doc_Ref=ENVPEP1512017EN&p_File_name=ENVPEP1512017_EN.pdf
